USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 36 of 62
UPTIME – 0x3004 – Time elapsed since last start
Bit 31 30 29 28 27 26 25 24
UPTIME[31:24]
R/W R R R R R R R R
Bit 23 22 21 20 19 18 17 16
UPTIME[23:16]
R/W R R R R R R R R
Bit 15 14 13 12 11 10 9 8
UPTIME[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
UPTIME[7:0]
R/W R R R R R R R R
 Bit 31:0 – Time elapsed since last start
These registers show the number of seconds elapsed from the last start (or restart).
VIN – 0x3006 – Input Voltage
Bit 15 14 13 12 11 10 9 8
VIN[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
VIN[7:0]
R/W R R R R R R R R
 Bit 15:0 – Input voltage
This register shows current input voltage in dV units (sampled in the same time slice of VOUT and
IOUT).
VOUT – 0x3007 – Output voltage
Bit 15 14 13 12 11 10 9 8
VOUT[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
VOUT[7:0]
R/W R R R R R R R R
 Bit 15:0 – Output voltage
This register shows output voltage in V units (sampled in the same time slice of VIN and IOUT).
IOUT – 0x3008 – Output current
