SAES SIP POWER - Page 37

USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 37 of 62
Bit 31 30 29 28 27 26 25 24
IOUT[31:24]
R/W R R R R R R R R
Bit 23 22 21 20 19 18 17 16
IOUT[23:16]
R/W R R R R R R R R
Bit 15 14 13 12 11 10 9 8
IOUT[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
IOUT[7:0]
R/W R R R R R R R R
 Bit 31:0 – Output current
These registers show output current in nA units (sampled in the same time slice of VIN and
VOUT).
Settings Registers
These registers are useful to retrieve or set current power supply settings.
VOUT_SETPOINT – 0x4000 – Output voltage set-point
Bit 15 14 13 12 11 10 9 8
VOUT_SETPOINT[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
VOUT_SETPOINT[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 15:0 – Output voltage set-point
This register contains output voltage set point in V units. The minimum allowed value is 1000V, the
maximum allowed value is 6000V.
VOUT_RAMP_INTV – 0x4001 – Output voltage ramping interval
Bit 31 30 29 28 27 26 25 24
VOUT_RAMP_INTV[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 23 22 21 20 19 18 17 16
VOUT_RAMP_INTV[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15 14 13 12 11 10 9 8
VOUT_RAMP_INTV[15:8]
