USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 38 of 62
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
VOUT_RAMP_INTV[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 31:0 – Output voltage ramping interval
These registers contain output voltage ramping interval in ms units. The minimum allowed value is
1000 ms, the maximum allowed value is 60000ms.
SW_MODE – 0x4003 – Switches mode
Bit 15 14 13 12 11 10 9 8
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
SW3_MODE SW2_MODE SW1_MODE
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15:6 – Reserved bits
These bits are reserved for future use.
Bit 5:4 – SW3 Mode
This field contains switch SW3 mode. Allowed modes are:
0 – SW3 switch is bypassed (OFF)
1 – SW3 switch is in simple mode (SIMPLE)
2 – SW3 switch is in window mode (WINDOW)
Bit 3:2 – SW2 Mode
This field contains switch SW2 mode. Allowed modes are:
0 – SW2 switch is bypassed (OFF)
1 – SW2 switch is in simple mode (SIMPLE)
2 – SW2 switch is in window mode (WINDOW)
Bit 1:0 – SW1 Mode
This field contains switch SW1 mode. Allowed modes are:
0 – SW2 switch is bypassed (OFF)
1 – SW2 switch is in simple mode (SIMPLE)
SW1_THR – 0x4004 – Switch SW1 threshold
Bit 31 30 29 28 27 26 25 24
SW1_THR[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 23 22 21 20 19 18 17 16
SW1_THR[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15 14 13 12 11 10 9 8
SW1_THR[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
