USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 39 of 62
SW1_THR[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 31:0 – Switch SW1 threshold
These registers contain switch SW1 threshold in nA units.
SW2_THR_MIN – 0x4006 – Switch SW2 low threshold
Bit 31 30 29 28 27 26 25 24
SW2_THR_MIN[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 23 22 21 20 19 18 17 16
SW2_THR_MIN[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15 14 13 12 11 10 9 8
SW2_THR_MIN[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
SW2_THR_MIN[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 31:0 – Switch SW2 low threshold
These registers contain switch SW2 low threshold in nA units.
SW2_THR_MAX – 0x4008 – Switch SW2 high threshold
Bit 31 30 29 28 27 26 25 24
SW2_THR_MAX[31:24]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 23 22 21 20 19 18 17 16
SW2_THR_MAX[23:16]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 15 14 13 12 11 10 9 8
SW2_THR_MAX[15:8]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
Bit 7 6 5 4 3 2 1 0
SW2_THR_MAX[7:0]
R/W R/W R/W R/W R/W R/W R/W R/W R/W
 Bit 31:0 – Switch SW2 high threshold
These registers contain switch SW2 high threshold in nA units.
SW3_THR_MIN – 0x400a – Switch SW3 low threshold
Bit 31 30 29 28 27 26 25 24
