SSV9 Installation and Setup Guide
11
R2
Making Connections
Making Connections
Connections Overview
Camera Connection
Connect up to 6 cameras to the SSV9 using camera connectors CH1 through CH6.
NOTE: Camera channels
Channels 2, 3, and 4 are special purpose cameras. To ensure full functionality, assign these channels appropriately,
as dened in the legend in the table on the following page.
