SSV9 Installation and Setup Guide
4
R2
Introduction
Introduction
This document introduces the SSV9 Six-Channel DVR Monitor and
provides instructions for its installation and system conguration.
The SSV9:
• Enables you to connect and record up to 6 cameras simultaneously.
• Supports NTSC and PAL standards.
• Comprises a built-in GPS receiver and G-sensor
• Supports 2 micro SD cards up to 128GB each.
Specications
Panel Size 9” LED Digital Panel
Video system NTSC / PAL Automatic detection
Resolution 1280 X 3 (RGB) X720
Brightness 450 cd/m
2
Contrast ratio 500:1
Screen mode 16:9
Field of view Top 85° / Bottom 85° / Left 85° / Right 85°
Video Inputs 6CH
Audio Output 0.5W speaker
Dot pitch 0.15525(H) × 0.15525(V) mm
Active area 198.72(H) × 111.78(V) mm
Power supply DC9-36V / Automatic Power On/O by ACC
Operating temp. (-20°C ~ +75°C )
Storage temp. (-30°C ~ +85°C )
Weight 600g
Trigger 6CH
External Dimensions L236.5XW 182XD35.9
