Safeline MX2 - Measurements and Components List

6
100
80
83
53
89,5
69,5
12 12
15,4
16
155
90
141
76
83
53
n
6
17,3
141
155
90
76
53
110,5
n
6
23,5
130
78
42
92
18
155
89
117
53
29
SafeLine MX2 v.5.2.1 EN
Flush mount SafeLine MX2
with pictograms
Article number: *SLMX_Rec-Pic
Flush mount SafeLine MX2
with pictograms and emer-
gency alarm button.
Article number: *SLMX_Rec-PicB
Surface mount SafeLine MX2
with pictograms
Cable hole diameter: 8mm
Article number: *SLMX_SM-Pic
Surface mount SafeLine MX2
with pictograms and emer-
gency alarm button
Cable hole diameter: 8mm
Article number: *SLMX_SM-PicB
SafeLine MX2 COP
Article number: *SLMX_COP
Measurements
and
components list
