Safeline SL6+ - Default Chapter; Table of Contents; Remote Configuration with Telephone: Step

2
SL6+ v.3.30 EN
Introduction
Content
Introduction
Technical data 3
General information 4
O verview
Description of the bus system 5
System overview 5
Overview SL6+ main unit 6
Insta llation
Overview SL6+ voice station 7
Mounting 9
Wiring diagram SL6+ main unit 10
Wiring diagram voice station 11
Wiring diagram voice station screw terminals 12
Activating the SIM card 13
Startup
LED indication front panel 14
LED indication for pictogram in car 15
Startup procedure 16
Conguration
Congure with Safeline CONNECT 17
Parameters unique for SafeLine CONNECT 18
Conguration with PC 19
Conguration with telephone 20
Remote conguration with telephone: Step 1 21
Remote conguration with telephone: Step 2 22
On-site conguration with telephone 23
Conguration examples 24
Parameter list 25
Relay functions 32
Operating
"DB Special" relay function 33
Calling with SafeLine SL6+ 34
Intercom between main station and voice station 34
Outgoing call 34
Emergency calling process 35
Fallback 36
Fallback LMS codes 37
Fire mode 38
Service
Battery function 39
Troubleshooting main unit 40
Troubleshooting voice station 41
Related test procedures 42
Internal operational failures 42
Certicate
Declaration of conformity 43
