- 12 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING PROCEDURE
1
11
1AL
AL AL
AL
A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
Enroll Loop Number or Loop & Serial Number via RF Learning (Continued)
The serial number of the device that has been learned will be displayed. “1AL” will be
displayed in front of the serial number.
Fault and restore the sensor again to confirm the serial number.
1
11
1ALC
ALC ALC
ALC A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The system will announce the Voice Descriptor for the zone and “1ALC” will be displayed
in front of the serial number.
Press [✻] to continue. System will advance to Prompt “1C”
E
EE
E
LOOP
LOOPLOOP
LOOP#/AUTO LEARN
AUTO LEARNAUTO LEARN
AUTO LEARN
Enter Loop Number or Loop & Serial Number via Manual Entry
Enter the desired loop number and press [✻] to continue (see the transmitter’s Installation
Instructions for specific loop designations). If “LEARNED” is displayed, the zone’s serial
number has already been enrolled.
Note: The loop number can be changed even if the zone has already been entered. Care
should be taken when using this feature. It is possible to make zones inoperable by
creating a mismatch of a working serial number/loop number combination. This
should be re-confirmed if the loop number is changed.
1-4 = Loop number for the zone of the transmitter being entered or learned
0 = Delete Serial Number prompt (F)
[
✻
] = Continue to the ENROLL MODE prompt (1A)
[#] = Return to previous prompt
F
FF
F
DELETE
DELETE DELETE
DELETE
ZONE
ZONEZONE
ZONE
Delete Zone Parameters
If 00 was entered in the Zone Type field or if 0 was entered in the Loop Number field,
confirmation of the delete request will delete all information associated with zone currently
being programmed.
Note: 00 was entered as a zone type in prompt (b), 00 will be retained and system will
advance to prompt (1C).
0 = Discard the delete request.
1 = Confirm the requested delete.
1
11
1A
AA
A
ENROLL
ENROLLENROLL
ENROLL
MODE
MODE MODE
MODE
Enroll Mode (this prompt applies to Manually enrollment only)
Confirm, delete or enter Serial Number
0 = Skip to the VOICE DESCRIPTOR prompt (1C). If zone type is “00”, then skips to
DELETE SERIAL NUMBER prompt instead.
1 = Enroll now and proceed to SERIAL NUMBER prompt (1b) (If “LEARNED” is not
displayed).
2 = Copy the last serial number from the local memory buffer (If “LEARNED” is not
displayed).
9 = Delete existing serial number. (Only if “LEARNED” is displayed).
[
✻
] = Advance to the VOICE DESCRIPTOR prompt (1C). This will save all zone
parameters.
[#] = Return to the loop number prompt (E).
1
11
1b
SERIAL
SERIALSERIAL
SERIAL
NUMBER
NUMBERNUMBER
NUMBER
Serial Number (this prompt applies to Manually enrollment only)
Manually enter the 7-digit serial number printed on the transmitter. If an incorrect digit is
entered, press the [#] key to return to prompt (1A). When all 7 digits are entered, press
the [✻] key. The serial number will be copied into EEROM and the local memory buffer and
the system will return to the (1A) prompt and “LEARNED” will be displayed. If 52 seconds
pass and no entry is been made, the system will return to prompt (1A).
1AL
1AL 1AL
1AL A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The serial number of the device that has been learned will be displayed. “L” will be
displayed in front of the serial number.
Fault and restore the sensor again to confirm the serial number.
1ALC
1ALC1ALC
1ALC
A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The system will announce the Voice Descriptor for the zone and “LC” will be displayed in
front of the serial number.
Press [✻] to continue. System will advance to Prompt “1C”
Note: In order for all parameters to be accepted, you must advance to prompt (1C).
