- 7 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
51
5151
51
PERIOD
PERIOD PERIOD
PERIOD
T
TT
TEST
ESTEST
EST
REP
REP REP
REP
Periodic Test Report
(enter Test Code in field ✻64)
† [0]
0 = none; 1 = 24 hours; 2 = weekly; 3 = 30 days
52
5252
52
TEST
TEST TEST
TEST
REP
REP REP
REP
OFFSET
OFFSETOFFSET
OFFSET
First Test Report Offset
† [2]
0 = 24 hour; 1 = 6 hours; 2 = 12 hours; 3 = 18 hours
53
5353
53
SESCOA/RADIONICS
SESCOA/RADIONICSSESCOA/RADIONICS
SESCOA/RADIONICS
SESCOA/Radionics Select
[0]
0 = Radionics (0–9, B–F reporting);
1 = SESCOA (0–9 only reporting). Select 0 for all other formats.
54
5454
54
LACK
LACK LACK
LACK
OF
OF OF
OF
USAGE
USAGEUSAGE
USAGE
Lack of Usage Notification
[0]
0 = Disabled
1 = 1 day
2 = 7 days
3 = 27 days
4 = 90 days
5 = 180 days
6 = 365 days
55
5555
55
REPORT
REPORT REPORT
REPORT
CHANNELS
CHANNELSCHANNELS
CHANNELS
Reporting Channels
[0]
0 = Telco Line (no Radio)
1 = LRR/IP(Digital Communication only) and Telco Line
3 = LRR/IP (Digital Communication only) (no Telco Line)
5 = LRR/IP (Digital Communication with AAV) (Telco Line connections for 2-way voice
session only, if applicable)
57
5757
57
FALSE AL
FALSE ALFALSE AL
FALSE ALA
AA
ARM OPTS
RM OPTSRM OPTS
RM OPTS
False Alarm Options
[7]
Value Cancel Alarm Display
Auto Stay Arming
Exit Time Restart/Reset
0 = Disabled Disabled Disabled
1 = Disabled Disabled Enabled
2 = Disabled Enabled Disabled
3 = Disabled Enabled Enabled
4 = Enabled Disabled Disabled
5 = Enabled Disabled Enabled
6 = Enabled Enabled Disabled
7 = Enabled Enabled Enabled
Note: The control validates the data entered in this field. If the selection is not valid it will emit a single
long beep indicating that the selection has been rejected. The control replaces the selection
with the default value “7”, which is displayed on the keypad, and advances to the next field.
58
5858
58
RF
RF RF
RF
JAM
JAM JAM
JAM
DETECTION
DETECTIONDETECTION
DETECTION
RF Jam Detection
Note: For event logging option 2 must be selected.
[0]
0 = no RF Jam Detection; 1 = RF Jam Detect on, no CS report;
2 = RF Jam Detect on with CS report (if trouble/restore report is enabled in fields
✻
60,
✻
71)
† Entering a number other than the one specified may give unpredictable results.
TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES (✻59–✻76, & ✻89):
With a 3+1 or 4+1 Standard Format: Enter a code in the first box: 1–9, 0, B, C, D, E, or F. Enter "#+10" for 0, "#+11" for B, "#+12" for C,
"#+13" for D, "#+14" for E, "#+15" for F.
A "0" (not "#+10") in the first box will disable a report.
A "0" (not "#+10") in the second box will result in automatic advance to the next field when programming.
With an Expanded or 4+2 Format: Enter codes in both boxes (1st and 2nd digits) for 1–9, 0, or B–F, as described above.
A "0" (not "#+10") in the second box will eliminate the expanded message for that report.
A "0" (not "#+10") in both boxes will disable the report.
With ADEMCO Contact ID Reporting: Enter any digit (other than "0") in the first box, to enable zone to report (entries in the second boxes
will be ignored). A "0" (not "#+10") in the first box will disable the report.
Examples: For Code 3 (single digit), enter: 3 | 0
For Code 3 2 (two digits), enter: 3 | 2
For Code B 2 (Hexadecimal), enter: #+11 | 2
To Next Page
