42 FP5/GP5 User’s Manual
n014
Mid. output frequency
(Mid Frequency)
Unit: 0.1Hz
Setting range: 0.1~399.9Hz
3Hz 76
n015Mid. frequency voltage
(Mid Voltage)
Unit: 0.1V
Setting range: 0.1~255.0V (510V for 460V units)
17.2V
(34.4V)
76
n016
Minimum output
frequency
(Min Frequency)
Unit: 0.1Hz
Setting range: 0.1~10.0Hz
1.5Hz 76
n017Minimum output voltage
(Min Voltage)
Unit: 0.1V
Setting range: 0.1~50.0V (510V for 460V units)
11.5V
(23.0V)
76
n018
Acceleration time 1
(Accel Time 1)
Unit: 0.1s (1s for 1000s and above)
Setting range: 0.0~3600s
10.0s 50,96
n019Deceleration time 1
(Decel Time 1)
Unit: 0.1s (1s for 1000s and above)
Setting range: 0.0~3600s
10.0s 50,96
n020Acceleration time 2
(Accel Time 2)
Unit: 1s
Setting range: 0~255s
10.0s 50
n021
Deceleration time 2
(Decel Time 2)
Unit: 1s
Setting range: 0~255s
10.0s 50
n022S-curve selection
(S-Curve Select)
LED Setting
LCD Setting
0 No S-curve
1 0.2s
2 0.5s
3 1.0s
0.2s 68
n023
Display mode
(Display Units)
Setting
Display
0 0.1Hz
1 0.1%
2~39 rpm (input # of motor poles)
40~3999 custom
0 -
n024Frequency reference 1
(Reference 1)
Setting depends on n023 setting.
Range: 0~9999
0.0Hz 64,95
n025
Frequency reference 2
(Reference 2)
Setting depends on n023 setting.
Range: 0~9999
0.0Hz 64
n026Frequency reference 3
(Reference 3)
Setting depends on n023 setting.
Range: 0~9999
0.0Hz 64
n027Frequency reference 4
(Reference 4)
Setting depends on n023 setting.
Range: 0~9999
0.0Hz 64
n028
Not used - - - -
n029
Not used - - - -
n030
Jog frequency
(Jog Reference)
Setting depends on n023 setting.
Range: 0~9999
6.0Hz 60
n031Frequency upper limit
(Ref Upper Limit)
Unit: 1%
Setting range: 0~109%
100% 69
n032Frequency lower limit
(Ref Lower Limit)
Unit: 1%
Setting range: 0~100%
0% 69
n033
Motor rated current
(Motor Rated FLA)
Unit: 0.1A Range: 10~200% inverter rated current
Unit is 1A, when setting is more than 1,000A
kVA
dependent
62,96
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
