A-2 DIGITAL OPERATOR MONITOR DISPLAY
The following table describes the contents of the digital operator monitor
display.
Digital Operator Monitor Display
Name
(LCD Operator Display)
Description
Frequency Reference
(Frequency Ref)
·Frequency reference can be monitored/set.
·Setting/display unit depends on display mode (n023).
Output Frequency
(Output Freq)
·Output frequency is displayed.
·Display unit depends on display mode (n023).
Output Current
(Output Amps)
Output current is displayed in units of 0.1A (1A for 1,000A and above).
Output Power
(Output Power)
Output power is displayed in units of 0.1kW (1kW for 1,000kW and
above).
FWD/REV Run Command
(Forward/Reverse)
·FWD/REV run command can be monitored/set.
·Setting enabled during run command from digital operator.
·FWD run displays “Forward”, REV run displays “Reverse”.
Monitor
(Monitor U-XX)
The following conditions can be monitored.
No.Contents
U-01Frequency reference
U-02Output frequency
U-03Output current
U-04Output voltage reference is displayed in units of 1V.
U-05DC voltage is displayed in units of 1V.
U-06Output power
U-07
Input terminal status is displayed (terminals S1 to S6).
U-08
Inverter status is displayed.
1:S1 closed
1:S2 closed
1:S3 closed
1:S4 closed
1:S5 closed
1:S6 closed
Always blank
_ 11 11 11
1:During run
1:Reverse run
1:Inverter ready
1:Fault
1:MODBUS error
Always blank
1:MA-MC output OFF
1:M1-M2 output OFF
11
-
1 11 11
Appendix A-2
Digital Operator Monitor Display
