FP5/GP5 User’s Manual 7
1.2 SPECIFICATIONS
FP5/GP5
Inverter Model
CIMR-P5U
20P420P721P522P223P725P527P5 20112015 -
Output Characteristics
Motor Output (HP) * 0.5 1 2 3 5 7.5 10 20 25 -
Capacity (kVA) 1.2 2.3 3.0 4.2 6.7 9.5 13 19 24 -
Rated Output
Current (A)-VT**
3.2 6 8 11 17.5
27 36 54 68 -
Rated Output
Current (A)-CT**
3.2 6 8 11 17.5 25 33 49 64 -
Max. Voltage
3-Phase, 200/208/220/230V
(Proportional to input voltage)
Rated Output Frequency 0.1 to 400 Hz
Overload Capacity - VT 120% Rated Output Current for 1 minute
Overload Capacity - CT 150% Rated Output Current for 1 minute
Power Supply
Input Current (A) 3.9 7.2 9.6 13.2 21 33 44 65 82 -
Rated Voltage &
Frequency
3-Phase
220 - 230V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
CIMR-P5U 40P440P741P542P243P744P045P547P540114015
Output Characteristics
Motor Output (HP) * 0.5 1 2 3 5 7.5 10 15 20 25
Capacity (kVA) 1.4 2.6 3.7 4.7 6.1 8.6 11 14 21 26
Rated Output
Current (A)-VT**
1.9 3.6 5.1 6.6 8.5 11.7 14.8
21.028.634.0
Rated Output
Current (A)-CT**
1.9 3.6 5.1 6.6 8.5 11.7 14.8 18 28.6 34.0
Max. Voltage
#
3-Phase, 380/400/415/440/460V
(Proportional to input voltage)
Rated Output Frequency 0.1 to 400 Hz
Overload Capacity-VT**
120% Rated Output Current for 1 minute
(Model 47P5 is rated 150% / 1 minute)
Overload Capacity-CT** 150% Rated Output Current for 1 minute
Power Supply
Input Current (A) 2.3 4.3 6.1 8.0 10.2 14.017.8 26.035.040.0
Rated Voltage &
Frequency
#
3-Phase
380 -440 - 460V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
Chapter 1 - Receiving & Installation
Specifications
* HP ratings based on standard NEMA 4-pole motor data.
#
For 380V operation, the motor rated current must be less than or equal to the inverter
rated current.
** VT: Variable Torque rating (n116=1), CT: Constant Torque rating (n116=0)
Note: Shaded areas indicate factory settings.
