FP5/GP5 User’s Manual 96
Monitor
(Monitor U-XX)
U-09Last 4 faults are displayed.
U-10Last 4 digits of software revision number are displayed.
U-11
U-12
Elapsed time is displayed as follows:
U-13PID feedback is displayed in units of 0.1Hz.
U-15Kilowatt-hour meter (4 least significant digits)
U-16Kilowatt-hour meter (2 most significant digits)
Acceleration Time 1
(Accel Time 1)
Acceleration time 1 (n018) can be set/read in units of 0.1s
(1s for 1,000s and above).
Deceleration Time 1
(Decel Time 1)
Deceleration time 1 (n019) can be set/read in units of 0.1s
(1s for 1,000s and above).
V/f Pattern Selection
(V/f Selection)
V/f pattern selection (n010) can be set during stop.
Frequency Reference Gain
(Terminal FV Gain)
Frequency reference gain (n048) can be set during stop.
Frequency Reference Bias
(Terminal FV Bias)
Frequency reference bias (n049) can be set during stop.
Motor Rated Current
(Motor rated FLA)
Motor rated current (n033) can be set during stop.
PID Selection
(PID Mode)
PID selection (n084) can be set during stop.
Energy Saving Selection
(Energy sav Sel)
Energy saving selection (n096) can be set during stop.
PRGM Mode
(Parameter nXXX)
Parameters can be set/read during stop.
Name
(LCD Operator Display)
Description
X X X X X X
Elapsed time (in units of 1 hour)
U-10 (last 4 digits)
U-11 (first 2 digits)
279,620 hours maximum
Appendix A-2
Digital Operator Monitor Display
