46 FP5/GP5 User’s Manual
n065
Elapsed timer selection
(Elapsed Timer)
LED
Setting LCD Setting Description
0 Time Power is ONAccumulate time during power on
1 Time Running MtrAccumulate time during running
Time
Running
Mtr
-
n066
Elapsed timer 1
(Elapsed Time 1)
Unit: 1 hour Range: 0~9999
* Initial value becomes 0 only when initialized dur-
ing CPF4 occurrence.
* -
n067Elapsed timer 2
(Elapsed Time 2)
Unit: 10,000 hours Range: 0~27
* Initial value becomes 0 only when initialized dur-
ing CPF4 occurrence.
* -
n068DC injection current
(DCInj Current)
Unit: 1%
Setting range: 0~100%
100% = inverter rated current
50% 54,75
n069
DC injection time at stop
(DCInj Time @ Stop)
Unit: 0.1s
Setting range: 0.0~10.0s
0.0s 54
n070DC injection time at start
(DCInj Time @ Start)
Unit: 0.1s
Setting range: 0.0~10.0s
0.0s 55,75
n071
Torque compensation
gain
(Torq Comp Gain)
Unit: 0.1
Setting range: 0.0~3.0
(normally, no adjustment is necessary)
1.0 72
n072Stall prevention during
deceleration
(StallP Decel Sel)
LED
Setting LCD Setting
0 Disabled
1 Enabled
Enabled 54
n073Current limit/Stall preven-
tion level during accelera-
tion
(StallP Accel Lvl)
Unit: 1% Setting range: 30~200%
When level is set to 200%, current limit during
acceleration is disabled.
kVA
dependent
52
n074Current limit/Stall preven-
tion level during running
(StallP Run Level)
Unit: 1% Setting range: 30~200%
When level is set to 200%, current limit during
running is disabled.
kVA
dependent
53
n075Frequency agree set point
(Freq Det Level)
Unit: 0.1Hz
Setting range: 0.0~400.0Hz
0.0Hz 57,84
n076
Frequency agree
detection width
(Freq Det Width)
Unit: 0.1Hz
Setting range: 0.0~25.5Hz
2.0Hz 84
n077Over/Undertorque
detection OL3
(Torq Det Sel)
LED
Setting LCD Setting Description
0 Disabled Detection disabled
1 OT/Spd Agree/AlmOvertorque detection at speed agree;
continue running after detection.
(Alarm)
2 OT/Run/Alm Overtorque detection at run; continue
running after detection. (Alarm)
3 OT/Spd Agree/FltOvertorque detection at speed agree;
coast to stop after detection. (Fault)
4 OT/Run/Flt Overtorque detection at run; coasts to
stop after detection. (Fault)
5 UT/Spd Agree/AlmUndertorque detection at speed
agree; continue running after detec-
tion. (Alarm)
6 UT/Run/Alm Undertorque detection at run; con-
tinue running after detection. (Alarm)
7 UT/Spd Agree/FltUndertorque detection at speed
agree; coast to stop after detection.
(Fault)
8 UT/Run/Flt Undertorque detection at run; coast to
stop after detection. (Fault)
Disabled
73
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
Chapter 3 - Programming Features
FP5/GP5 Parameters
