Sagem Monetel EFTsmart - Appendix 3: Cable Fixing

INSTALLATION MANUAL
page 37 / 40 3300039745 R11 000 04/735
APPENDIX 3 : CABLE FIXING
Other possibilities
To dismount:
Push the nut out with
the knurled screw,
Pinch and push the part.
Mounting on the other side

Right side or left side
Screw the knurled screw about 2 turns until
the nut remains in place by itself.
Unscrew the knurled screw, taking care
that the nut remains in place
Pressing the nut
with your finger,
re-screw the
knurled screw
just one turn,
then push the
knurled screw to
disengage the
nut from its
position.
Push
Screw until it becomes tight.
You may remove the knurled
screw after the operation.
