SAJ HS2/AS2 Series User Manual

HS2/AS2 Series
15
16
Model
HS2-3K-S2/
AS2-3K-S
HS2-3.6K-S2/
AS2-3.6K-S
HS2-4K-S2
/ AS2-4K-S
HS2-4.6K-S2/
AS2-4.6K-S
HS2-5K-S2/
AS2-5K-S
HS2-5K-S2-B/
AS2-5K-S-B
HS2-6K-S2/
AS2-6K-S
AC Input [On-grid]
Rated AC Voltage/Range [V]
L+N+PE, 220,230,240/180～280
Rated Input Frequency [Hz]
50,60
Max. Input Current [A]@230Vac
26.1
32.0
34.8
40.0
43.5
43.5
52.2
AC Output [Back-up]
Max. Output Power [VA]
3000
3680
4000
4600
5000
5000
6000
Max. Output Current [A]
13.6
16.7
18.2
20.9
22.7
22.7
27.3
Peak Output Apparent Power [VA]
3600,60s
4416,60s
4800,60s
5520,60
6000,60s
6000,60s
7200,60s
Rated AC Voltage/Range [V]
L+N+PE, 220,230,240/180～280
Rated Output Frequency/Range [Hz]
50,60/45～55,55～65
Output THDv (@ Linear Load)
<3%
Efficiency
Max. Efficiency
97.6%
Euro Efficiency
97.0%
Protection
Battery Input Reverse Polarity Protection
Integrated
Over Load Protection
Integrated
AC Short Circuit Current Protection
Integrated
DC Surge Protection
Integrated
AC Surge Protection
Integrated
Anti-islanding Protection
Integrated
AFCI Protection
Optional
RSD Protection
Optional
Interface
PV Connection
MC4/H4
AC Connection
Plug-in connector
Battery Connection
Quick connector
Display
LED+APP
Communication
Wi-Fi/Ethernet/4G(Optional)
General Parameters
Topology
Non-isolated
Operating Temperature Range
-10～50℃, >45 ℃ derating
Cooling Method
Natural Convection
Ambient Humidity
0-100% Non-condensing
Altitude
4000m (>3000m Power Derating)
Noise [dBA]
<35
Model
HS2-3K-S2/
AS2-3K-S
HS2-3.6K-S2/
AS2-3.6K-S
HS2-4K-S2
/ AS2-4K-S
HS2-4.6K-S2/
AS2-4.6K-S
HS2-5K-S2/
AS2-5K-S
HS2-5K-S2-B/
AS2-5K-S-B
HS2-6K-S2/
AS2-6K-S
Ingress Protection
IP65
Dimensions [H*W*D] [mm]
354*626*365
Weight [kg]
25 (HS2), 23.7 (AS2)
Warranty [Year]
5/10/15/20
Standard
EN62109-1/2, EN61000-6-1/2/3/4, EN50438, EN50549, C10/11, IEC62116, IEC61727, RD1699, RD413, UNE 206006,
UNE 206007, NTS, CEI 0-16, AS4777.2, NBR16149, NBR 16150 VDE-AR-N 4015, VDE 0126-1-1
Battery
Model
BU2-5.0-HV1/
BU2-5.0-HV5
BU2-10.0-HV1/
BU2-10.0-HV5
BU2-15.0-HV1/
BU2-15.0-HV5
BU2-20.0-HV1/
BU2-20.0-HV5
Battery Module
BU2-5.0-HV1/5 (1P32S 102.4V 50Ah)
No. of Modules
1
2
3
4
Rated Energy [kWh]
5.0
10.0
15.0
20.0
Usable Energy [kWh]
4.5
9.0
13.5
18.0
Dimension (H*W*D)[mm]
261*626*365
522*626*365
783*626*365
1044*626*365
Weight [kg]
50.5/52.5
101/105
151.5/157.5
202/210
Nominal Voltage [V]
102.4
204.8
307.2
409.6
Operating Voltage [V]
89.6～115.2
179.2～230.4
268.8～345.6
358.4～460.8
Max. Charge Current [A]
30
Max. Discharge Current [A]
30
General Data
Ingress Protection
IP65
Mounting
Wall-Mounted / Ground-Mounted
Operating Temperature Range
Charging: 0～50℃; Discharging: -10～50℃
Ambient Humidity
0～95% non-condensing
Cooling Method
Natural convection
Communication
CAN
Warranty [Year]
5/10
Applicable Standard
IEC62619(Cell&Pack)/EN62477-1/EN61000-6-1/2/3/4/UN38.3
