SAJ PDS23-2SR75 User Manual

PDS23 Series
- 12 -
2.4 PDS23 Solar Pump Controller Model Description
2.4.1 Model Description
PDS 23 - 4 T 5R5
① ② ③ ④ ⑤
Segment
Description
Options
①
PDS series
②
Series ID
2: Series of 2nd generation.
3: Apply to three-phase induction motor
③
Rated Output Voltage
2: 220V three phase; 4: 380V three phase
④
Input Voltage
S: 310VDC rating, MPPT range 280VDC ～360VDC(Note 1)
T: 540VDC rating, MPPT range 500VDC ～600VDC(Note 2)
⑤
Motor Power Rating
004:4kW; 5R5:5.5kW; R: decimal point
Note 1: Supporting Alternating Current input, with voltage rating of 220VAC single phase connected
to terminal R&T.
Note 2: Supporting Alternating Current input, with voltage rating of 380VAC three phase connected to
terminal R, S and T.
2.4.2 PDS23 Solar Controller General parameters
General Parameters
Protection
Surge Protection
Integrated
Overvoltage Protection
Integrated
Undervoltage Protection
Integrated
Locked pump Protection
Integrated
Open circuit Protection
Integrated
Short circuit Protection
Integrated
Overheated Protection
Integrated
Dry Run Protection
Integrated
Communication
MODBUS Communication Card
Optional, RS-485 Isolated
Others
Ambient Temperature Range
-20°C ～60°C; >45°C, Derating as Required
Cooling Method
Fan Cooling
Ambient Humidity
≤ 95%RH
Standard Warranty(month）
18
Certificates
IEC/EN 61800-5-1,IEC/EN 61800-2:2004,IEC/EN 61800-3:2004,CE
