SAJ PDS23-2SR75 User Manual

PDS23 Series
- 15 -
Controller Model
PDS23-4T075
PDS23-4T093
PDS23-4T110
PDS23-4T132
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-700V
Recommended PV Array Power[kW]
90～120
112～149
132～176
159～211
Alternate AC Generator
Input Voltage
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
157
180
214
256
Power and VA Capability[kVA]
114
134
160
192
Output Data
Output Voltage, Rated
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
150
176
210
253
Output Power, Rated[kW]
75
93
110
132
Output Frequency
0～50Hz/60Hz
Controller Model
PDS23-4T160
PDS23-4T200
PDS23-4T220
PDS23-4T250
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-700V
Recommended PV Array Power[kW]
192～256
240～320
264～352
300～400
Alternate AC Generator
Input Voltage
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
307
385
430
468
Power and VA Capability[kVA]
231
250
280
355
Output Data
Output Voltage, Rated
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
304
377
426
465
Output Power, Rated[kW]
160
200
220
250
Output Frequency
0～50Hz/60Hz

SAJ PDS23-2SR75 Specifications

General

Brand	SAJ
Model	PDS23-2SR75
Category	Controller
Language	English
