PDS23 Series
- 13 -
2.4.3 PDS23 Solar Controller Input and Output Data
PDS23-2SXX Input and Output Data
Controller Model
PDS23-2SR75
PDS23-2S1R5
PDS23-2S2R2
Input Data
Max Input Voltage(Voc)
DC 450V
Recommended Voltage, at MPP
DC 280-360V
Recommended PV Array Power[kW]
0.9 ～1.2
1.8 ～2.4
2.7 ～3.5
Alternate AC Generator
Input Voltage
Single Phase AC 200-240V(±10%)
Max Amps(RMS)[A]
8.2
14
23
Power and VA Capability[kVA]
1.5
3
4
Output Data
Output Voltage, Rated
Three Phase AC 200-240V
Max Amps(RMS)[A]
4
7
9.6
Output Power, Rated[kW]
0.75
1.5
2.2
Output Frequency
0～50Hz/60Hz
PDS23-4TXX Input and Output Data
Controller Model
PDS23-4T2R2
PDS23-4T004
PDS23-4T5R5
PDS23-4T7R5
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-700V
Recommended PV Array Power [kW]
2.7 ～3.5
4.8 ～6.4
6.6 ～8.8
9 ～12
Alternate AC Generator
Input Voltage
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
5.8
10.5
14.6
20.5
Power and VA Capability[kVA]
4
5.9
8.9
11
Output Data
Output Voltage, Rated
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
5.1
9
13
17
Output Power, Rated[kW]
2.2
4
5.5
7.5
Output Frequency
0～50Hz/60Hz
