SAJ PDS23-4T004 - Page 15

PDS23 Series
- 14 -
Controller Model
PDS23-4T011
PDS23-4T015
PDS23-4T18R5
PDS23-4T022
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-700V
Recommended PV Array Power[kW]
13.2～17.6
18～24
22.2～29.6
26.4～35.2
Alternate AC Generator
Input Voltage
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
26
35
38.5
46.5
Power and VA Capability[kVA]
17
21
24
30
Output Data
Output Voltage, Rated
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
25
32
37
45
Output Power, Rated[kW]
11
15
18.5
22
Output Frequency
0～50Hz/60Hz
Controller Model
PDS23-4T030
PDS23-4T037
PDS23-4T045
PDS23-4T055
Input Data
Max Input Voltage(Voc)
DC 800V
Recommended Voltage, at MPP
DC 500-700V
Recommended PV Array Power[kW]
36～48
44～59.2
54～72
66～88
Alternate AC Generator
Input Voltage
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
62
76
92
113
Power and VA Capability[kVA]
40
57
69
85
Output Data
Output Voltage, Rated
Three Phase AC 380/400/415/440V(±15%)
Max Amps(RMS)[A]
60
75
91
112
Output Power, Rated[kW]
30
37
45
55
Output Frequency
0～50Hz/60Hz
