SAJ PDS23 Plus User Manual

PDS23 Plus Series
- 12 -
2.4.3 Input and Output Parametersof PDS23 Plus Solar Pump Controller
Controller Model
PDS23
Plus 2.2K
PDS2Plus
4K
PDS23Pl
us 5.5K
PDS23Pl
us 7.5K
PDS23Pl
us 11K
Input Data
PV Source
Max Input Voltage(Voc)
DC800V
Recommended Voltage, at MPP
DC500～700V
Recommended PV Array Power
[kW]
2.7～3.5
4.8～6.4
6.6～8.8
9～12
13.2～
17.6
Alternate AC Generator
Input Voltage
380/400/415/440VAC(±15%), Three Phase
Power and VA Capability[kVA]
4.0
5.9
8.9
11.0
17
Output Data
Output Power, Rated[kW]
2.2
4.0
5.5
7.5
11
Output Voltage, Rated
380/400/415/440VAC(±15%), Three Phase
Rated Output Amps(RMS)[A]
5.1
9.0
13.0
17.0
25.0
Max Amps(RMS)[A]
9.0
13.0
17.0
25.0
32.0
Output Frequency
0～50Hz/60Hz
Note: according to different regions, the recommended PV array power is 1.2 ~ 1.6 times the
power of the controller.
