SAJ R6-10K-S2-X User Manual

R6 Series Solar Inverter
11
12
Model
R6-5K-S2-X
R6-6K-S2-X
R6-7K-S2-X
R6-8K-S2-X
R6-9K-S2-X
R6-10K-S2-X
DC Input
Max. PV Array Power [Wp]@STC
7500
9000
10500
12000
12000
12000
Max. DC Voltage [V]
600
MPPT Voltage Range [V]
90-550
Rated DC Voltage [V]
360
Start Voltage [V]
100
Min. DC Voltage [V]
80
Max. DC Input Current [A]
16/16
Max. DC Short Circuit Current [A]
19.2/19.2
No. of Strings per MPPT
1/1
No. of MPPT
2
DC Switch integrated
Integrated
AC Output [On-grid]
Rated AC Power [W]
4999
6000
7000
8000
9000
10000
Rated Apparent Power [VA]
4999
6000
7000
8000
9000
10000
Max. Apparent Power [VA]
4999
6600
7700
8800
9900
10000
Max. AC Current [A]
21.7
30.0
35.0
40.0
45.0
45.5
Current Inrush [A]
30
Max. AC Fault Current [A]
65
100
Max. AC Over Current Protection [A]
53
76
Rated AC Voltage
L+N+PE , 220, 230,240;180-280
Rated Output Frequency [Hz]
50, 60 / 44-55, 54-65
Power Factor [cos φ]
0.8leading～0.8lagging
Total Harmonic Distortion [THDi]
< 3%
Efficiency
Max. Efficiency
98.2%
98.2%
98.2%
98.2%
98.2%
98.2%
Euro Efficiency
97.8%
97.8%
97.8%
97.8%
97.8%
97.8%
Protection
Overvoltage Protection
Integrated
DC Insulation Resistance Detection
Integrated
DCI Monitoring
Integrated
GFCI Monitoring
Integrated
Grid Monitoring
Integrated
AC Short Circuit Current Protection
Integrated
AC Grounding Detection
Integrated
Model
R6-5K-S2-X
R6-6K-S2-X
R6-7K-S2-X
R6-8K-S2-X
R6-9K-S2-X
R6-10K-S2-X
DC Surge Protection
Type Ⅱ
AC Surge Protection
Type Ⅲ（type Ⅱ optional）
Overheat Protection
Integrated
Anti-islanding Protection
AFD
AFCI Protection
Optional
Interface
AC Connection
Quick connector
DC Connection
MC4/H4
Display
LED+APP
Communication Port
RS232+RJ45+DRM
Communication
Wi-Fi/Ethernet/4G/PLC (optional)
Load Monitoring
Whole day (optional)
General Data
Topology
Non-isolated
Consumption at Night [W]
<1
Consumption at Standby [W]
<8
Operating Temperature Range
-40℃～+60℃ (>45℃ derating)
Cooling Method
Natural convection
Ambient Humidity
0%～100%
Altitude
4000m (>3000m derating)
Noise [dBA]
<35
Ingress Protection
IP65
Mounting
Wall mounting
Dimensions [H*W*D] [mm]
391*532*202
Weight [kg]
16.5
16.5
17.3
17.3
17.3
17.3
Warranty [Year]
5（Standard）/10/15/20（Optional）
Applicable Standard
IEC/EN62109-1/2, EN61000-6-1/2/3/4, IEC61683, IEC60068-2, IEC62116, IEC61727, EA/MEA,VDE0126-1-1/A1,
CEI 0-21, VDE-AR-N 4105, AS/NZS4777.2, CQC NB/T 32004, G98/G99, NBR 16149, NBR 16150,
C10/11,RD1669,UNE206006, UNE206007,EN50438
