SAJ Suntrio Plus 15K User Manual

Suntrio Plus Series
-13-
3.4 Datasheet
Sunttrio Plus 12K/15K/17K/20K
Type
Suntrio Plus
12K
Suntrio Plus
15K
Suntrio Plus
17K
Suntrio Plus
20K
Input (DC)
Max. DC Power [W]
14520 18150 20570 24200
Max. DC Voltage [V]
1000
MPPT Voltage Range [V]
180-900
Nominal DC Voltage [V]
600
Start Voltage[V]
200
Min. DC Voltage[V]
180
Max. DC Input Current PV1 / PV2 [A]
22/11 22/22 22/22 22/22
Number of MPPT 2
Number of DC Connection Sets per
MPPT
2/1 2/2 2/2 2/2
DC Switch Integrated
Output (AC)
Rated AC Power [W]
(@230V,50Hz)
12000 15000 17000 20000
Max. AC Power [VA]
13200 16500 18700 22000
Rated AC Current[A]
17.4 21.7 24.6 29.0
Max. AC Current [A]
20.0 25.0 28.3 33.0
Nominal AC voltage/ range 3/N/PE, 220/380V,230/400V,240/415V;180V-280V/312V-485V
Grid frequency/ range 50Hz,60Hz /44Hz-55Hz,54Hz-65Hz
Power factor,adjustable 0.8 leading~0.8lagging
Total Harmonic Distortion (THDi)
< 3% (at nominal power)
Feed-in Grid
3L+N+PE
Efficiency
Max. Efficiency
98.3% 98.4% 98.5% 98.5%
Euro Efficiency (at 600Vdc)
98.0% 98.1% 98.2% 98.2%
MPPT Accuracy >99.5%
Protection
Internal Over-voltage Protection
Integrated
DC Insulation Monitoring Integrated
DCI Monitoring Integrated
GFCI Monitoring Integrated
Grid Monitoring Integrated
AC Short Circuit Current Protection
Integrated
Thermal Protection Integrated
