Sako V780 - Page 24

18
P1 Motor Parameters
Function
Code
Parameter
Name
Setting Range Default Property
P1-00
Motor type
selection
0: Common asynchronous motor
2: Permanent magnetic
synchronous motor
0 ★
P1-01
Rated motor
power
0.1kW ～ 1000.0kW
Model
dependent
★
P1-02
Rated motor
voltage
1V ～ 2000V
Model
dependent
★
P1-03
Rated motor
current
0.01A ～ 10.00A
(AC drive power ≤ 2.2kW)
Model
dependent
★
P1-04
Rated motor
frequency
0.01Hz ～ maximum frequency
Model
dependent
★
P1-05
Rated motor
rotational speed
1rpm ～ 65535rpm
Model
dependent
★
P1-10
No-load current
(asynchronous
motor)
0.01A ～ P1-03
Model
dependent
★
P1-37
Auto-tuning
selection
0: No auto-tuning
1: Asynchronous motor static
auto-tuning
2: Asynchronous motor complete
auto-tuning
0 ★
6.1 Brief introduction of function code
