Sako V780 - Page 30

24
P4 Input Terminals
Function
Code
Parameter
Name
Setting Range Default Property
P4-11 Terminal command mode
0: Two-line mode 1
1: Two-line mode 2
2: Three-line mode 1
0 ★
P4-12 Terminal UP/DOWN rate 0.001Hz/s ～ 65.535Hz/s 1.00Hz/s ☆
P4-13 AI curve 1 minimum input 0.00V ～ P4-15 0.00V ☆
P4-14
Corresponding setting of AI
curve 1 minimum input
-100.0% ～ +100.0% 0.0% ☆
P4-15 AI curve 1 maximum input P4-13 ～ +10.00V 10.00V ☆
P4-16
Corresponding setting of AI
curve 1 maximum input
-100.0% ～ +100.0% 100.0% ☆
P4-17 AI1 󽗉lter time 0.00s ～ 10.00s 0.10s ☆
P4-18 AI curve 2 minimum input 0.00V ～ P4-20 0.00V ☆
P4-19
Corresponding setting of AI
curve 2 minimum input
-100.0% ～ +100.0% 0.0% ☆
P4-20 AI curve 2 maximum input P4-18 ～ +10.00V 10.00V ☆
P4-21
Corresponding setting of AI
curve 2 maximum input
-100.0% ～ +100.0% 10.00V ☆
P4-22 AI2 󽗉lter time 0.00s ～ 10.00s 0.10s ☆
P4-23 AI curve 3 minimum input -10.00V ～ P4-25 -10.00V ☆
P4-24
Corresponding setting of AI
curve 3 minimum input
-100.0% ～ +100.0% -100.0% ☆
P4-25 AI curve 3 maximum input P4-23 ～ +10.00V 10.00V ☆
6.1 Brief introduction of function code
