25
6.1 Brief introduction of function code
P4 Input Terminals
Function
Code
Parameter
Name
Setting Range Default Property
P4-26
Corresponding
setting of
AI curve 3
maximum input
-100.0% ～ +100.0% 100.0% ☆
P4-27
Panel
potentiometer
󽗉lter time
0.00s ～ 10.00s 0.10s ☆
P4-28
HDI Pulse
minimum input
0.00kHz ～ P4-30 0.00kHz ☆
P4-29
Corresponding
setting of HDI
minimum input
-100.0% ～ 100.0% 0.0% ☆
P4-30
HDI maximum
input
P4-28 ～ 100.00kHz 50.00kHz ☆
P4-31
Corresponding
setting of HDI
pulse maximum
input
-100.0% ～ 100.0% 100.0% ☆
P4-32 HDI 󽗉lter time 0.00s ～ 10.00s 0.10s ☆
P4-33
AI curve
selection
Unit's digit (AI1 curve selection)
Curve 1 (2 points, see P4-13 to F4-16)
Curve 2 (2 points, see P4-18 to F4-21)
Curve 3 (2 points, see P4-23 to F4-26)
Curve 4 (4 points, see A6-00 to A6-07)
Curve 5 (4 points, see A6-08 to A6-15)
Ten's digit (AI2 curve selection)
Curve 1 to curve 5 (same as AI1)
Hundred's digit (AI3 curve selection)
Curve 1 to curve 5 (same as AI1)
321 ☆
