F.30 Alarm 3 address 00:00 - FF:FF 00:00
F.31 Alarm 4 address 00:00 - FF:FF 00:00
F.32 Alarm 5 address 00:00 - FF:FF 00:00
F.33 Alarm 6 address 00:00 - FF:FF 00:00
F.34 Alarm 7 address 00:00 - FF:FF 00:00
F.35 Alarm 8 address 00:00 - FF:FF 00:00
F.36 Alarm 9 address 00:00 - FF:FF 00:00
F.3 Alarm 10 address 00:00 - FF:FF 00:00
F.38 Restore controller factory settings
0: No
1: Yes
0
F.39
Modbus (Holding register) type param-
eter reading and changing tool
0 - 999 0
F.40
Modbus (Coil register) type parameter
reading and changing tool
0 - 999 0
F.41 Control panel version - -
F.42
Fan’s controlled by 0..10 VDC signal
start delay time in seconds
0 - 120 0
F.43 0..10 VDC Disable / Enable
0: OFF
1: ON
0
F.44
Restore factory settings of PRV control
board.
Note: accessible only by connecting to
PRV controller
0: No 1: Yes 0
F.45 Tool for air ow adjustment. 0 - 100 0
To restore factory settings, service password “022” should be reentered.
Due to limited number of symbols in segment display, modbus addresses of “CUSTOM” device are
entered as HIGH and LOW bytes in hexadecimal (HEX) system. Using buttons B2 and B3, select
HIGH or LOW bytes, “H.00” and “L.00” are displayed respectively.
14. MODBUS REGISTER READ AND RECORD TOOL
Modbus register read and record tool indicated in F.39 and F.40 items is useful when you want to
set the unit‘s parameters, which by default are not controlled by remote controller, but these param-
eters are accessible via Modbus. F.39 is used for Holding type registers and F.40 used Coil registers.
Using the Tool:
1. Modbus register address is indicated and conrmed by “MAX” button.
2. The tool reads the address value and shows on a segmental display (the value ashes).
3. Change the value with “+” and “-” button and conrm with the MAX button.
4. The tool records the value to indicated register and return to the service menu.
