SALICRU
MEASURES
I.VOLTAGE V12=398.3
V23=397.7 V31=400.2
OUT. VOLT V1N=230.1
V2N=229.8 V3N=230.0
BYP.VOLT. V1N=227.3
V2N=224.9 V3N=219.8
BATTERY VOLTAGES
P=419.8V N=420.8V
INP. APPARENT POW.
L1=9.8KVA
INPUT ACTIVE POWER
L1=9.7KW
INPUT TOTAL POWER
28.8KVA 28.7KW
OUTPUT APPARENT POW
L2=9.1KVA
OUTPUT ACTIVE POWER
L2=8.8KW
OUT. P.F. L1=0.87
L2=0.96 L3=0.94
FREQUENCIES (Hz)
I=49.9 B=49.9 O=50.0
I.VOLTAGE V1N=227.4
V2N=225.2 V3N=220.3
OUT. CURR. I1=40.9
I2=39.8 I3=37.7
BYP. CUR. I1=0.5
I2=0.4 I3=0.9
CHAR. BAT. CURRENTS
P=3.6A N=3.6A
INP. APPARENT POW.
L2=9.6KVA
INPUT ACTIVE POWER
L2=9.6KW
INPUT P.F. L1=0.99
L2=1.00 L3=1.00
OUTPUT APPARENT POW
L3=8.6KVA
OUTPUT ACTIVE POWER
L3=8.1K W
OUTPUT LD: L1=47.0%
L2=45.5% L3=43.0%
TEMPERATURES (ºC)
TR=42 TI=41 TB=27
I.CURRENT I1=45.2
I2=42.8 I3=40.7
INV. VOLT V1N=230.0
V2N=230.7 V3N=229.9
DC BUS VOLTAGES
P=420.3V N=421.0V
DISC. BAT. CURRENTS
P=0.0A N=0.0A
INP. APPARENT POW.
L3=9.4KVA
INPUT ACTIVE POWER
L3=9.4KW
OUTPUT APPARENT POW
L1=9.4K VA
OUTPUT ACTIVE POWER
L1=8.2K W
OUTPUT TOTAL POWER
27.1K VA 25.1KW
TOTAL LOAD
IN:53.8% OUT:52.3%
ESTIMAT. BACKUP TIME
16 minutes
screen 2.0 screen 2.1
screen 2.4
screen 2.7
screen 2.10
screen 2.13
screen 2.16
screen 2.19
screen 2.22
screen 2.25
screen 2.28
screen 2.31
screen 2.2
screen 2.5
screen 2.8
screen 2.11
screen 2.14
screen 2.17
screen 2.20
screen 2.23
screen 2.26
screen 2.29
screen 2.32
screen 2.3
screen 2.6
screen 2.9
screen 2.12
screen 2.15
screen 2.18
screen 2.21
screen 2.24
screen 2.27
screen 2.30
screen 2.33
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
()
By pressing (ESC) key from any screen of any submenu, it is gone
back to main screen (Screen 0.0).
Fig. 46. Screen 2.0 «Measurements» and its submenus.
Table 6 shows the screens that ARE NOT AVAILABLE in some set-
tings, taking the “three phase input / three phase output” setting as
maximum conceptual exponent and represented in submenu of Fig.
46, which shows the measurement figures as an example.
For frequency converters and single phase equipments, the dis-
played measurements will be according to its condition.
