Nominal power (kVA) 5 7.5 10 15 20 30 40 50 60 80 100
Nominal power (kW) Depending on the input/output setting and power supply voltage (See chart 9)
MANUAL BYPASS (MAINTENANCE)
Type Make before break
Nominal voltage
Single phase 115V, 120V, 127V or 133V -
Three phase 3x200V, 3x208V, 3x220V or 3x230V (4 wires: 3 phases + N)
Frequency 50 / 60 Hz
SHORT CIRCUIT CURRENT (kA) 6 10 25 100
GENERAL
Total efficiency (100% linear load) (%) 89 89.5 90 91 91.5 92 93 92.5 92 93.0
BATTERIES
Quantity 38 36 40 38 40
(8)
Type Pb-Ca
Floating voltage per battery 13.65 V at 20ºC
Compensation of the battery floating voltage Adjustable (preset to –18 mV/ºC)
Capacity (Ah) 7 12 18 26 40 65
Standard charging current (Cx0,2) (A) 1.4 2.4 3.6 5.2 8 13
Battery terminal torque According to battery manufacturer
Fitted in the same UPS cabinet YES NO
DIMENSIONS AND WEIGHTS FOR UPS CONFIGURATIONS WITH STANDARD BACK UP TIME
Quantity of cabinets 1 (UPS + batteries) 1 (UPS) / 1 (batteries)
Maximum
dimensions(mm)
(Depth x Width x
Height)
CUBE3+ / CUBE3+ B1
775x450x1100
880x590x1325 850x900x1905
CUBE3+ B / CUBE3+ B B1 880x870x1325 850x1225x1905
Batteries - 1050x650x1325 850x1305x1905
Casters without brake. Equipment / batteries YES / - YES / YES YES / NO NO / NO
Cabinet weight (kg)
CUBE3+ B1 97 99 102 147 172 - - - - - -
CUBE3+ B B1 99 101 105 150 175 - - - - - -
CUBE3+ 207 209 235 319 417 185 265 290 290 540 550
CUBE3+ B 209 211 237 322 420 190 275 310 310 570 580
External batteries - - - - - 424 501 594 1096
Table 8. Technical specifications for equipments with (LV) voltages.
9.2. TECHNICAL SPECIFICATIONS, EQUIPMENTS (HV).
Nominal power (kVA) 7.5 10 15 20 30 40 50 60 80 100 120 160 200
Nominal power (kW) Depending on the input/output setting and power supply voltage (See chart 9)
INPUT
Nominal voltage
Single phase 220V, 230V or 240V -
Three phase 3x380V, 3x400V or 3x415V (4 wires: 3 phases + N)
Input voltage range +15% / –20% (configurable)
Frequency 50 / 60 Hz ±5 Hz (selectable from 0.5, 1, 2 or 5 Hz)
Total input current distortion
(depending on the quality of input mains)
100 % load: THD-i < 1.5 %
50 % load: THD-i < 2.5 %
10 % load: THD-i < 6.0 %
100 % load: THD-i < 1.0 %
50 % load: THD-i < 2.0 %
10 % load: THD-i < 5.0 %
100 % load: THD-i < 1.5 %
50 % load: THD-i < 2.0 %
10 % load: THD-i < 6.0 %
Current limit High overload: PFC limit (discharging batteries)
Power factor 1.0 from 10% load
Rated conditional
short-circuit current
-Icc- (kA)
III/III (with common input) 6 10
III/III-B (rectifier input) 6 10
III/III-B (bypass input) 6 10
(L) I/I (with common input) 6 10 - - -
(L) I/I-B (rectifier input) 6 10 - - -
(L) I/I-B (bypass input) 6 10 - - -
(M) I/III-B (rectifier input) 6 10 - - -
(M) I/III-B (bypass input) 6 10 - - -
(N) III/I-B (rectifier input) 6 10 - - -
(N) III/I-B (bypass input) 6 10 - - -
