Salus RT520RF User Manual

25
Using or , move to the
next option.
Using or , select correct
MAX temperature setpoint value.
Confirm by .
Now, using
or , select
correct MIN temperature setpoint
value. Confirm by .
Now, using or , select
proper settings (ON / OFF).
Thermostat will go to the next
option. Here you can decide if your
receiver is allowed to work in manual
mode or not. To set it press
button.
Thermostat will go back to SERVICE
option. To go back to the main
screen wait 10 seconds or press
button as long as main screen will be
displayed.
Confirm by
.
Press
.
14
16
20
13 15
21
3
19
17 18

Salus RT520RF Specifications

General

Display	LCD
Temperature Range	5°C to 35°C
Power Supply	2 x AA Batteries
Frequency	868 MHz
Frost Protection	Yes
Mounting	Wall-mounted
Wireless	Yes
Voltage	3 V DC
Switching Current	3 A
Temperature Control Accuracy	±0.5°C
Programmable	Yes, 5/2 day or 7 day programming
Operating Modes	Manual, Holiday
Communication	RF Communication
Battery Life	2 years
Dimensions	120 mm
