14.3.4. Steam condenser capacity
The steam condenser is ready to be fitted on a Modular model
of:
Deck
Type
CV-E
Capacity
CV-NXD
Capacity
EM Up to 4 Decks
E From 1 deck up to 2 From 3 decks up to 4
EMD From 1 deck up to 2 From 3 decks up to 4
ED Up to 1 Deck From 2 decks up to 4
NXE Up to 1 Deck From 2 decks up to 4
NXM Up to 2 Decks From 3 decks up to 4
NXD From 1 decks up to 3
LXP Up to 1 Deck From 2 decks up to 4
NOTE: This number of modules is for illustration purposes,
since the number of condensers depends on the type of pro-
duct to be prepared, remembering that greater water content
will produce reduced condenser performance.
