SD-13546 SD-15452 SD-17568 SD-18577 SD-18582 SD-21510 SDL-25411 SDL-30516
ΦC
165 190 210 218 223 266 310 370
ΦD
130 170 190 190 190 225 275 290
ΦD1
147 170 190 200 205 240 275 345
ΦE (기준경)
100 130 160 160 160 200 230 260
ΦF
80 85 120 120 120 160 166 240
ΦG
65 70 85 95 100 125 140 190
H
M52x2.0 M60x2.0 M75x2.0 M85x2.0 M90x2.0 M112x2.0 M130x2.0 M180x3.0
ΦJ
46 52 68 77 82 103 117.5 166.5
K
36 36 40 40 40 48 46 42
N
63 76 92 102 106 128 138 188
ΦP
79.8 89.8 105.8 115.8 119.8 173.5 170 222
ΦS
116 135 154 164 175 208 230 278
T
125 134 141 149.5 160.5 174.5 204 230
U
159.5 149.5 173 180.5 186.5 216.5 258 290
V max
15 22 25 25 25 35 46 51
V min
-10 -3 -4 -4 -5 0 -4 0
W max
41.5 51 58.5 57.5 53 63 75 76
W min
16.5 26 29.5 28.5 23 28 25 25
Z
5 5 5 5 5 5 6 5
A1
8.5 8.5 11 11 11 14 18 17.5
B1
117.5 107.5 122.5 129.5 133 153.5 178.5 206
C1
30 30 30 35 35 30 45 45
E1
M6 M6 M6 M6 M6 M6 M6 M6
F1
M10 TAP
DP'20
M10 TAP
DP'20
M10 TAP
DP'20
M10 TAP
DP'20
M10 TAP
DP'20
M12 TAP
DP'20
M16 TAP
DP'32
M16 TAP
DP'32
G1
125.5 115.5 132.5 139.5 143.5 163 194.5 221
H1
105 118 145 155 160 190 206 256
J1
75 80 90 95 104 120 135 160
K1
47 47 47 47 47 47 47 47
L1
15 15 21 15 15 15 20 20
M1
48 55 71 80 85 106 123 170
Q1
M5 TAP
DP'10
M6 TAP
DP'10
M6 TAP
DP'10
M6 TAP
DP'10
M6 TAP
DP'13
M6 TAP
DP'10
M6 TAP
DP'12
M6 TAP
DP'12
S1
G 3/8 G 3/8 G 3/8 G 3/8 G 3/8 G 3/8 G 3/8 G 1/2
T1
7 7 8 5 8 6 6 7
W1
M52x1.5 M58x1.5 M74x1.5 M84x2.0 M89x2.0 M120x2.0 M124x2.0 M173x2.0
ΦX1
50 56 71.5 81 86 117 121.5 170.5
Y1
21 27 28 26 25 34 29 45
U1
4 9 8 9 6 6 9 8
Z1
6-M8x95 6-M8x85 6-M10x100 8-M8x110 6-M10x110 6-M12x120 8-M12x140 12-M12x160
