SAMCHULLY STA Series - Page 15

Instruction Manual
15
Instruction Manual
A
B
S
C
D
S
C A
D
B
[ 그림 / Fig 5 ]
[ 그림 / Fig 6 ]
SR STA-1
STA-2
STA-3 / 3.1 / 3.2 STA-4 STA-5/5.1
STA-6
A CLAMP
G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4” G 3/8” PT 3/8” G 3/8” PT 3/8” G 3/8” PT 3/8”
B UNCLAMP
G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4” G 3/8” PT 3/8” G 3/8” PT 3/8” G 3/8” PT 3/8”
C CENTRAL LUBRICATION
G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/8” PT 1/8”
G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/8” PT 1/8”
D DRAIN
G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4”
S COMPRESSED AIR
G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/8” PT 1/8”
G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4”
SR STAB-3/3.1/3.2 STAB-4 STAB-5/5.1
STAB-6
A CLAMP
G 1/4” PT 1/4” G 3/8” PT 3/8” G 3/8” PT 3/8” G 3/8” PT 3/8”
B UNCLAMP
G 1/4” PT 1/4” G 3/8” PT 3/8” G 3/8” PT 3/8” G 3/8” PT 3/8”
C CENTRAL LUBRICATION
G 1/8” PT 1/8”
G 1/8” PT 1/8” G 1/8” PT 1/8” G 1/8” PT 1/8”
D DRAIN
G 1/8” PT 1/8” G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4”
S COMPRESSED AIR
G 1/8” PT 1/8”
G 1/4” PT 1/4” G 1/4” PT 1/4” G 1/4” PT 1/4”
