27
SAMIX GmbH
Operation
NOTICE
The current operating mode is shown on the display by the illumination of the triangle above
AUTO (automatic lifting) or below MANUAL (manual lifting).
NOTICE
When the operating mode is changed, the oscillation arm of the SAMIX
®
ES500 is automati-
cally moved to the corresponding start position.
Fig. 13: Specify the mixing time using the "-" and "+" buttons
The mixing time can be set in a range between 0 seconds and 9 minutes and 55
seconds.
Fig. 14: Switch to the mode to select the speed setting using the "Speed" button
