SAMIX
®
ES500
28
Fig. 15: Specify the speed setting using the "-" and "+" buttons
The speeds (rpm) for the speed settings are listed in the following table:
Speed setting Speed Speed setting Speed
0 650 rpm 5 1450 rpm
1 810 rpm 6 1610 rpm
2 970 rpm 7 1770 rpm
3 1130 rpm 8 1930 rpm
4 1290 rpm 9 2100 rpm
Tab. 4: Value table of speed settings
NOTICE
You can switch to the mode to select the mixing time or the speed by pressing the "Time" or
"Speed" button. The value which can currently be changed using the "-" and "+" buttons is
displayed with a point in the respective number eld.
