Samson 3214 Mounting And Operation Instructions

EB 8331-3 EN 3-3
Design and principle of operation
3.4 Technical data
Table 3-1: Technical data · Type 3374
Type3374 -10 -11 -15 -17 -21 -26 -31 -36
Version with Yoke Ring nut Yoke
Ring
nut
Yoke
Ring
nut
Fail-safe action Without Extends Retracts
Rated travel mm 30 15 30 15
Stroking speed
Standard mm/s 0.125 0.1 0.125
Fast mm/s 0.25 – 0.25
In the event of
fail-safe action
mm/s – 1.25
Transit time for rated travel
Standard s 240 120 240 300 120 120 120 120
Fast s 120 60 120 – 60 60 60 60
In the event of fail-safe
action
s – – – – 12 12 12
12
Thrust Retracts 2.5kN 5kN 0.5kN
Extends 2.5kN 5kN 2kN
Manual override With hex wrench With hex wrench only possible
when supply voltage is
connected (see the 'Operation'
section). Adjustment not possible
after fail-safe action has been
triggered.
Motor switch-off Torque switches
Duty type S1-100%accordingtoEN60034-1
Electrical connection
Supply voltage V 230,+10/–15%
24,+10/–15%
Power line frequency Hz 50 or 60 50 50 or 60
Power consumption VA 7.5/13
1)
13 10.5/16
1)
