Samson 3244 Operating Instructions

EB 8026 EN 13
Markings on the control valve
The valve nameplate (80) is afxed to the
ange (see Fig.2).
80
Fig.2: Nameplate on the ange
2.2 Actuator nameplate
See associated actuator documentation.
2.3 Material number
The seat and plug of the valves have an item
number written on them. Specifying this item
number, you can contact us to nd out which
material is used. Additionally, a seat code is
used to identify the trim material. This seat
code is specied on the nameplate (17). For
more details on the nameplate, see sec-
tion2.1.

Samson 3244 Specifications

General

Brand	Samson
Model	3244
Category	Control Unit
Language	English
