Design and principle of operation
Dimensions and weights
Table1 to Table4 provide a summary of the dimensions and weights of the standard version
of Type3244 Valve as well as the version with insulating section or bellows seal. The lengths
and heights in the dimensional drawings are shown on p.19.
The associated actuator documentation applies to actuators, e.g. for SAMSON pneumatic
actuators:
uT8310‑1 for Type3271 and Type3277 Actuators up to 750cm² actuator area
Table1: Dimensions of the standard version of Type3244 Valve (DIN version)
Valve DN 15 20 25 32 40 50 65 80 100 125 150
L mm 130 150 160 180 200 230 290 310 350 400 480
H1 mm 235 270 360 375
H2 mm 70 80 85 100 105 120 130 140 150 200 210
Note
Risk of hearing loss or deafness due to loud
noise.
Wear hearing protection when working near
the valve.
