Markings on the device
Order no. Type6116-
x x x x x x x x x x x x x x x
Direc-
tion of
action
Increasing/increasing 1
Increasing/decreasing
1)
2
Electrical
connection
½-14NPT 1
M20x1.5 2
Pneumatic
connection
Positioner attachment (without booster)
9)
0 6 0 1 1 0 0 0
¼-18NPT 1
ISO-228/1-G¼ 2
Degree of
protection
Without (vent for positioner attachment)
0 6 0 1 1 0 0 0
IP54 1
IP65 2
NEMA 4
10)
3
Output pres-
sure gauge
Without 0
With
1)
1
Temperature
range
T
min
≥–25°C(Type6109standard) 1 0
T
min
≥–45°C(Type6112subjectedtoroutinetest,metal
cable gland)
2 1
T
min
≥–40°C(Type6112standard) 2 2
Special ver-
sion
Without 0 0 0
IECExapproval:ExdIICT6/T5/T4Gb
2 2 5 1
EAC Ex approval: on request
1/2 2 5 2
KCS approval, Korea: on request
5 2 6 2
1)
Not for positioner attachment
2)
WithdegreeofprotectionIP54/IP65only
3)
Supply pressure max. 6 bar; output 5.6 bar
4)
Only with 0.2 to 1 bar/3 to 15 psi
5)
With ½ NPT electrical connection, degree of protection NEMA 4 or positioner attachment
6)
With½NPTelectricalconnection,degreeofprotectionIP65orpositionerattachment
7)
Without switch-off electronics and without potentiometer for zero point and span correction
8)
Specifysettingrange,e.g."setto0.1to4bar";outputpressuremax.8bar.Initialvalueraisedto
max.3.0bar(specialversion)
9)
Only with Ex d or explosion-proof according to CSA and FM standards
10)
Only explosion-proof or intrinsically safe according to CSA and FM standards
11)
4to12mAand12to20mAinputonlyupto4.0barspan
12)
Onlywith0.2to1bar(3to15psi)and0.4to2bar(6to30psi)output
