7
Customer inquiries
Should you have any inquiries, please sub
-
mit the following details:
4
Type designation and order no. (see na
-
meplate)
4
Order number (see nameplate)
4
Serial number
4
Nominal size and valve version
4
Pressure and temperature of process me
-
dium
4
Flow rate in m³/h
4
Bench range (signal pressure range),
e.g. 1.4 to 2.3 bar, when a pneumatic
actuator is used
4
Installation drawing
EB 8135/8136 EN 23
Customer inquiries
50(1.96)
H
H2
L
Fig. 17 · Dimensional drawing for Type 3535
Dimension applies to a
plug stem inserted as far
as it will go

Samson Valve Series Specifications

General

Type	Control Valve
Category	Control Unit
Series	Valve Series
Sizes	1/2" to 12"
Materials	Stainless Steel
Actuator Type	Pneumatic, electric
Valve Body	Globe
Connection Type	Flanged, Threaded
Certifications	ASME, PED
