6 Electrical Parts List
6-1
LS19PEBSBE/EDC 932B,SAB3/S19P0-LPE,19,LCD-MO,NETHERLAND
0.1 M0001 BN90-01055J ASSY COVER FRONT;LS19PE (932B),HSD,BLACK 1 S.N.A
..2 T0003 BN96-04142Q ASSY COVER P-FRONT;LS19PE (932B),HSD Pan 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 BN61-03222A GUIDE-PANEL;LS17PEW,SECC,T 0.5 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.45 S.N.A
...3 M0112 BN63-02878D COVER-FRONT;LS19PE (S/M932B),ABS,2.4,HB, 1 S.N.A
...3 T0022 BN64-00534B KNOB CONTROL;PEBBLE,ABS,HB,BK26 1 S.N.A
...3 T0023 BN64-00597B KNOB POWER;PEBBLE,black highglossy 1 S.N.A
...3 M0130 BN67-00193A LENS LED;PEBBLE,ABS HB,CLR 1 S.N.A
...3 M0145 BN96-04363A ASSY BOARD P-FUCNTION;Pebble,SJ06-01-023 1 S.A
....4 M0014 BN94-01300M ASSY PCB MAIN-SEDA,FUCHION PCB;PABBLE* 1 S.N.A
.....5 M2893 BN39-00774A LEAD CONNECTOR;Pebble,UL1061#28,UL/CSA,3 1 S.A
.....5 M2893 BN39-00788A LEAD CONNECTOR;Pebble,UL1061#28,4PIN,300 1 S.A
.....5 T0238 BN97-01597B ASSY AUTO;PEBBLE* 1 S.N.A
......6 T0313 3404-000299 SWITCH-TACT;12V,50mA,120gf,6x6x4.3mm,SPS 5 S.A
......6 T0174 BN97-01589M ASSY SMD;PABBLE 1 S.N.A
.......7 R110 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-001157 R-CHIP;750ohm,5%,1/10W,TP,1608 4 S.A
.......7 R110 2007-001157 R-CHIP;750ohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-001157 R-CHIP;750ohm,5%,1/10W,TP,1608 1 S.A
.......7 R110 2007-001157 R-CHIP;750ohm,5%,1/10W,TP,1608 1 S.A
.......7 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 3 S.A
.......7 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.......7 C120 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
.......7 PCB BN41-00793B PCB SUB-FUNCTION;Pebble,FR-1,1,1.1,1.6,8 1 S.N.A
....4 BN94-01310C ASSY PCB MISC-SEDA,POWER,BN96-;PABBLE 1 S.N.A
.....5 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
.....5 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
.....5 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
.....5 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
.....5 T0313 3404-001207 SWITCH-TACT;12V,50mA,160gf,6.2X6.2,SPST 1 S.A
.....5 SUBPCB BN41-00791A PCB SUB-POWER;Pebble,FR-1,1,1.0,1.6,36*1 1 S.N.A
0.1 M0002 BN90-01423A ASSY COVER REAR;LS19PEBSBE,BLACK_AUO 1 S.N.A
..2 M0013 BN96-06492A ASSY COVER P-REAR;LS19PE(AUO),,ABS HB,,B 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 T0060 BN61-02830A SPRING ETC;PEBBLE,SK5,1.0,LS19PEB,HRC 45 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.45 S.N.A
...3 M0014 BN63-02880B COVER-STAND BAR;PEBBLE,ABS HB,T2.6,BK26, 1 S.N.A
...3 BN63-02883B COVER-HINGE;PEBBLE,ABS HB,T2.6,BK26,HF-0 1 S.N.A
...3 M0006 BN63-04083A COVER-REAR;PEBBLE 19",ABS,2.6,HB,BK26 1 S.N.A
...3 T0102 BN73-00132B RUBBER-CAP;PEBBLE,ELASTOMER,BK07,HB 1 S.N.A
0.1 M0112 BN91-01212A ASSY SHIELD;LS19PEBSW/EDC 1 S.N.A
..2 BN63-02887A SHIELD-LAMP;PEBBLE,SPTE,0.3,19INCH 1 S.N.A
0.1 BN91-01803G ASSY LCD-ATZ;LS19PEB* 1 S.N.A
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA Remark
6 Electrical Parts List
6-1 LS19PEBSBE/EDC Parts List
