11 Disassembly and Reassembly
11-3
Description Picture Description
LVDS
INVERTER
FUNCTION
LVDS
INVERTER
FUNCTION
19"
17"
8. Disconnect cables.
(LVDS, INVERTER and FUNCTION cable)
9. Lift up the LCD panel.
10. LCD Panel
