11 Disassembly and Reassembly
11-1
11 Disassembly and Reassembly
11-1 Disassembly Block
LE 1729
LCD Monitor
ASSY, BASE
BASE*1
RUBBER FOOT *6
SCREW.P.CROSS,T.T-4*8,Zn
ASSY STAND
SCREW M4*10 *4
BACK COVER
BKT-VESA *4
ASSY FRONT BEZEL
STAND_REAR*1
HINGE *1
SCREW M4*10 *3
LENS*1
CONTROL BOARD*1
STAND_FRONT *1
BEZEL*1
BUTTON,FUNCTION *1
ASSY PANEL*1
SCREW M3*5, *4
CABLE 30P FFC
BOLT,#4-40*11.8,Ni *2
CHASSIS *1
PCBA I/F BOARD *1
Power Board *1
SCREW M3*6
CLIP,WIRE *1
SHIELING*1
Note: The DIS assembly direction please following direction of arrowhead
INNOLUX PANEL EN01
