14 Reference Infomation
14-3
Sync
Type
Pin No.
15-Pin D-Sub Signal Cable Connector
Separate
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
NC
DDC Return (GND)
GND-R
GND-G
GND-B
NC
Cable Detect
NC
Bi-Dr Data (SDA)
H-Sync.
V-Sync.
DDC Clock (SCL)
Red
Green + H/V Sync.
Blue
NC
DDC Return (GND)
GND-R
GND-G
GND-B
NC
Cable Detect
NC
Bi-Dr Data (SDA)
Not Used
Not Used
DDC Clock (SCL)
Sync-on-green
14-2 Pin Assignments
