Samsung AC024BXUPCH - AHU Control Unit Disassembly Guide

Disassembly and Reassembly
Samsung Electronics 3-25
■ MXD-U000XN
No. Parts Procedure Remark
1 Case top
(Front cover)
Turn off the power before disassembly
necessarily.
1) Push the middle area of the Case
top(front cover) and open it upward to
separate from the Case bottom(Rear
cover).
2 PCB 1) Remove 1ea screw from the PCB(Use
+Screw Driver) and push the rib down
to separate the PCB from the case.
3-1. AHU Control Unit
