Product specications
Specications
Model Name AE200RNWSEG AE260RNWSEG AE260RNWSGG AE200RNWMEG AE260RNWMEG AE260RNWMGG
Type Split Mono
Power source V/Hz
1Φ, 220-240V~,
50Hz
1Φ, 220-240V~,
50Hz
1Φ, 220-240V~,
50Hz
3Φ, 380-415V~,
50Hz
1Φ, 220-240V~,
50Hz
1Φ, 220-240V~,
50Hz
1Φ, 220-240V~,
50Hz
3Φ, 380-415V~,
50Hz
Operation
Range [Water]
Cooling °C 5~25 5~25 5~25 5~25 5~25 5~25
Heating °C 15~65 15~65 15~65 15~65 15~65 15~65
Sound Pressure
Cooling dB(A) 26 30 30 26 30 30
Heating dB(A) 26 30 30 26 30 30
Sound Power Heating dB(A) 40 44 44 40 44 44
Dimension
(HxWxD)
Net mm 595 x 1800 x 700 595 x 1800 x 700 595 x 1800 x 700 595 x 1800 x 700 595 x 1800 x 700 595 x 1800 x 700
Gross mm 700 x 2000 x 780 700 x 2000 x 780 700 x 2000 x 780 700 x 2000 x 780 700 x 2000 x 780 700 x 2000 x 780
Weight
Net kg 136 146 146 130 140 140
Gross kg 148 158 158 142 152 152
Connection
Pipe
(Regrigerant)
Liquid Inch 1/4" 1/4" 1/4" - - -
Gas Inch 5/8" 5/8" 5/8" - - -
Connection
Pipe (Floor
Heating)
Inlet mm 28 28 28 28 28 28
Outlet mm 28 28 28 28 28 28
Connection
Pipe (Domestic
Hot water)
Inlet mm 22 22 22 22 22 22
Outlet mm 22 22 22 22 22 22
Connection
Pipe (Monobloc
Outdoor)
Inlet mm - - - 28 28 28
Outlet mm - - - 28 28 28
Water Pump
Model Name - UPMM25-9.5 UPMM25-9.5 UPMM25-9.5 UPMM25-9.5 UPMM25-9.5 UPMM25-9.5
Maker - Grundfos Grundfos Grundfos Grundfos Grundfos Grundfos
Max. Vol
Flow
m
3
/h 5.5 5.5 5.5 5.5 5.5 5.5
Electric Heater Input Power W 2000 2000 6000 2000 2000 6000
Flow Sensor Set Point LPM 7 7 7
7 (~9kW
Outdoor)
12 (~16kW
Outdoor)
7 (~9kW
Outdoor)
12 (~16kW
Outdoor)
7 (~9kW
Outdoor)
12 (~16kW
Outdoor)
Expansion
Vessel
Volume Liter 8 8 8 8 8 8
Pressure Relief
Valve
Size Inch BSPP Male 1/2" BSPP Male 1/2" BSPP Male 1/2" BSPP Male 1/2" BSPP Male 1/2" BSPP Male 1/2"
Relief
Pressure
bar 2.9 2.9 2.9 2.9 2.9 2.9
Air Vent Valve Size Inch BSPP Male 3/8" BSPP Male 3/8" BSPP Male 3/8" BSPP Male 3/8" BSPP Male 3/8" BSPP Male 3/8"
Operating
Outdoor Temp
Range
Heating
°C
-25 ~ 35 -25 ~ 35 -25 ~ 35 -25 ~ 35 -25 ~ 35 -25 ~ 35
Cooling 10 ~ 46 10 ~ 46 10 ~ 46 10 ~ 46 10 ~ 46 10 ~ 46
DHW Water -25 ~ 43 -25 ~ 43 -25 ~ 43 -25 ~ 43 -25 ~ 43 -25 ~ 43
 Heat pump operating range of DHW : -25 ~ 35 °C
 At the temperature -25°C ~ -20°C, operation is available but capacity cannot be guaranteed.
