ENGLISH-55
03 INSTALLATION
No. Note No. Note
①
Service valve
⑦
T-Joint
②
3 way diverting valve
⑧
Expansion relief Valve
③
Drain Valve
⑨
T-Joint
④
T-Joint
⑩
Pressure reducing valve with integrated check valve and strainer
⑤
Tundish Tank Temp Temperature sensor for DHW tank
⑥
Expansion vessel
The table above contains the dierent components of the functional diagrams.
System conguration
For the reliable performance and durability, all parts as listed below ,including a relief valve, an expansion vessel, a drain
valve and pressure reducing valve , should be installed according to each national or regional standards. They are not
supplied by SAMSUNG.
- Pressure relief valve
- Expansion vessel
- Drain valve
- Tundish
- Expansion relief valve
- Pressure reducing valve
