Samsung AM300MXVGNR4ET - Page 64

64
Refrigerant pipe installation
3. Install the distribution header horizontally.
 Install the distribution header horizontally so that its ports does not face down.
9ʪͱиߣߢঌ
Horizon line
Socket Distribution header
Pipe
(Separately purchased item)
9ʪͱиߣߧঌ
Horizon line
Horizon line
< Liquid side >
9ʪͱиߣߧঌ
Horizon line
9ʪͱиߣߢঌ
Horizon line
< Gas side >
