7
ENGLISH
Preparing for installation
Outdoor unit combination
 Make sure to use an indoor unit that is compatible with DVM S.
 Indoor units can be connected within the range indicated in following table.
 If the total capacity of the connected indoor units exceeds the indicated maximum capacity, cooling and
heating capacity of the indoor unit may decrease.
 Total capacity of the connected indoor units can be allowed from 50% to 130% of the total outdoor unit
ʀɇΧɇʀϩц࢏ߢ࢏ߧנ࣑ĮЇϩʒͱͱθЇϩʀɇΧɇʀϩц࣒ƟͱϩɇʀɇΧɇʀϩцͱ˙ϩ˵ʪʀͱʪʀϩʪʒʒͱͱθЇϩϑߣ࢏ߥנ࣑ĮЇϩʒͱͱθЇϩ
capacity)
࢜
You can connect maximum 64 indoor units to the outdoor unit. Maximum quantity of connectable indoor
unit is set to 64 since outdoor unit only support up to 64 communication address. Indoor unit address can
ɵʪɇϑϑ˝ʪʒ˙θͱߢߨߥ࢏Ã˙ϩ˵ʪʒͱͱθЇϩɇʒʒθʪϑϑиɇϑɇϑϑ˝ʪʒ˙θͱߨߦߩ߫ࡥkߤߢߣʪθθͱθиͱʀʀЇθ࢏
࢜
đɇуЇߥߤǮɇࣛͱЇϩϩцΧʪʒͱͱθЇϩϑиϩ˵kkǤ࣑đĘůUk²ࡥđâĘǤ࣒ʀɇɵʪ
connected.
࢜
Do not install 1st-generation MCU and 2nd-generation MCU together.
ৄ ߣϑϩࣛ˝ʪʪθɇϩͱđAƸࡤđAƸࣛƊĘkkĘࡥđAƸࣛƊߤĘkçߣĘ
ৄ ߤʒࣛ˝ʪʪθɇϩͱđAƸࡤđAƸࣛƊĘkçߤĘࡥđAƸࣛƊߦĘkçߥĘࡥđAƸࣛƊߣĘkçߣĘ
࡛Use the following table to determine the size and number of outdoor units needed to achieve
ϩ˵ʪʀɇΧɇʀϩцθʪαЇθʪʪϩϑ࢏
CAUTION
Standard type (Heat pump)
Model name for combination AM080JXVAGH/ET AM100JXVAGH/ET AM120JXVAGH/ET AM140KXVAGH/ET AM160KXVAGH/ET AM180KXVAGH/ET
Number of individual outdoor units 111111
Combined
outdoor unit
AM080JXVAGH/ET 1
AM100JXVAGH/ET 1
AM120JXVAGH/ET 1
AM140KXVAGH/ET 1
AM160KXVAGH/ET 1
AM180KXVAGH/ET 1
AM200KXVAGH/ET
AM220KXVAGH/ET
AM240KXVAGH/ET
AM260KXVAGH/ET
Total capacity
of the
connected
indoor units
(Cooling)
Minimum (kW) 11.2 14.0 16.8 20.0 22.5 25.2
Maximum (kW) 29.1 36.4 43.7 52.0 58.5 65.5
Maximum number of connectable
indoor units
14 18 21 26 29 32
